CCS, DNV-GL, EC, MED Approved SOLAS 6-152 Persons Open Reversible Inflatable Liferaft

CCS, DNV-GL, EC, MED Approved SOLAS 6-152 Persons Open Reversible Inflatable Liferaft

Products - Life Saving Appliance - Life Raft
  • Material
    Rubber, Fabric
  • Production Standard
    SOLAS
  • Capacity
    6-152 Persons
  • Color
    International Orange
  • Type
    Open Reversible Inflatable Life Raft
  • Inflating
    Automatically
  • Place of Origin
    CHINA
  • Brand Name
    GH
  • Certification
    CCS, DNV-GL, EC, MED
  • Model Number
    SOLAS 6-152 Persons Open Reversible Inflatable Liferaft
  • Minimum Order Quantity
    1 Set
  • Price
    Negotiable
  • Packaging Details
    Plywood Box
  • Delivery Time
    5-30 Days
  • Payment Terms
    L/C, T/T
  • Supply Ability
    6000 Sets Per Month

CCS, DNV-GL, EC, MED Approved SOLAS 6-152 Persons Open Reversible Inflatable Liferaft

  • CCS, DNV-GL, EC, MED Approved SOLAS 6-152 Persons Open Reversible Inflatable Liferaft
  • CCS, DNV-GL, EC, MED Approved SOLAS 6-152 Persons Open Reversible Inflatable Liferaft
  • CCS, DNV-GL, EC, MED Approved SOLAS 6-152 Persons Open Reversible Inflatable Liferaft
Get Price Contact Now

The open reversible inflatable life raft is usually used for high speed ships, then it is usually equipped with Pack "B" which is less accessories inside.

The open reverisble inflatable life raft is approved by CCS, DNV-GL(EC/MED) and meets the following standards:
1. International Code of Safety for High-Speed Craft (2000), Annex 11
2. Chapter I of MSC48.(66) International Life-saving Appliance Code (LSA Code) and MSC.218(82),MSC.293(87)
3. Sections V of Parts1; Sections V of Parts 2of MSC.81(70) Revised Recommendation on Testing of Life-saving Appliances and MSC.295(87),MSC323.(89)
It is used for international category A high-speed craft.



Type K-6 K-10 K-25 K-30 K-50 K-65 K-100 K-152
Physical form Regular octagon Regular dodecagon Round Rectangular dodecagon
Capacity 6 10 25 30 50 65 100 152
Length ,mm, ±1000 2720 2720 4160 4580 5780 6560 9450 11500
Width, mm, ±1000 2720 2720 4160 4580 5780 6560 6000 8500
Height , mm, ±50 560 560 720 760 860 920 1000 1080
WP pressure,kPa 13.3 16
Specification of cylinder 3×2 3×2 6×2 7×2 14×2 18×2 14×4 22×4
Gas volume, g CO2, ±050 1700 1700 3500 4200 8600 10000 8600 13500
N2, ±020 160 160 240 280 600 1000 600 1500
Container Dia. (mm) 545 545 615 615 730 745 795 1050
Length(mm) 1045 1045 1090 1090 1440 1485 1695 2050
Total weight, kg ≤ 67 67 100 117 170 185 280 385
